4-Port Dual Beam Lens Antenna
EHS3AZA242

sliding

Detailed introduction
  • Electrical Specifications
    Product Name
    4-Port Dual Beam Lens Antenna
    Frequency (MHz)
    1710-2200/2200-2690
    Gain (dBi)
    15±1/17±1
    Front to back ratio (dB)
    25
    Horizontal3dB Beam width (°)
    28±4/23±3
    Vertical 3dB Beam width (°)
    26±4/23±3
  • Aircraft performance
    Mechanical Down-Tilt (°)
    0~20
    Connector
    4*7/16DIN-Female
    Antenna Dimension (mm)
    394×400×400
    Mounting Pole Diameter (mm)
    ￠50-114
    Packaging Dimension (mm)
    620×515×515
    Radome Material
    UPVC
Expand more
Related downloads
Product specifications
5g high speed, low delay and large capacity - 5g network architecture is the direction of network diversification, broadband, integration and intelligence. 5g is the foundation of the interconnection of all things. The main equipment solves the problem of high speed and low delay. Passive multi beam antenna can solve the problem of large capacity and provide better and more solutions.
